Articulated Vi Gauntlet STL

Articulated Vi gauntlet (file only); mechanically operated. Cutouts included for strip lights. Cut for 23cm(L)x23cm(W)x25cm(H) 3d printer build volume (standard home printer size). This model is in beta.

Project difficulty: hard

Model comes with instruction manual.

Please note that the instruction manual explains printing and assembly only. Additional instructions for wrist strap attachments, lights, motors, etc. are suggestions but not included in the manual in depth. These items are done by preference and not included in instructional support for this file.

Parts of the model cannot sit flat on the printer and must be printed on supports. This is intentional to minimize and hide any seams along the pieces.

Model body is 22.5in long, not including finger length. Scaling to your size may be necessary.

Estimated PLA requirement (1.75mm): 750 Meters (may vary by machine, supports, and infill)

Additional required materials (not included):

1. 3mm elastic cord
2. Clear fishing line
3. Adhesive of choice for joining PLA parts
4. Filler

Recommended additional tools to assist with assembly: metal needle files and flat nosed jewelry pliers.

Other materials as listed in the manual are suggestions only.

FAQ:

1) How long will it take me?

It is a large project that will require a large time investment. Testing groups took about 4 months to finish one gauntlet while working on other projects.

2) What about the left gauntlet?

The file can be mirrored for the other hand. If making two, keep in mind if both are articulated you will need assistance getting in and out of them. You may also choose to make one fixed with a grab bar instead of ease of use.

3) How does it work?

It is on a pulley system, with one pulley per finger. The best way I have found for the puppetry is having the motions be reversed, meaning that closing your hand will open the gauntlet fingers.

4) How much does it weigh?

How much it weighs exactly depends on what you put inside, but mine with all accessories weighs about 3.5lbs (for one).

5) This description says the model is in beta, what does that mean?

The model has been fully printed and tested. It is listed as being in beta because upgrades are still being made to the model, which is reflected in a lower price. Buying the model now entitles you to all future model updates and Vi's Season 1 Gauntlet. Some fixes that may occur while the model is in this state includes: tolerance changes to piece fittings and pegs, file name and organization, and optimizing divisions of the model.

This listing is for personal use only, not for resale or reproduction.

All sales final.
